Architecture

Handling time

• game holds the main in-game time.
• At the start:
  • The game time is zero
  • Each piece its (assumed) in-game time is zero
• Upon game::tick:
  • It is checked that game and each piece assume the same in-game time
  • The game time is updated
  • Each piece updates its idea of in-game time.
  • It is checked again that game and each piece assume the same in-game time. Pieces that are lagging did not update.

Handling user input

sequenceDiagram
    participant user
    participant game_view
    participant controller
    participant game
    participant chess_piece
    user->>game_view: sf::event
    Note right of game_view: game_view::process_events
    game_view->>user: For universal input (e.g. F4): done!
    Note right of game_view: process_events(game_view&, sf::event&)
    game_view->>controller: sf::event
    Note right of controller: controller::process_input
    controller->>user: If no keys in key and mouse bindings: done!
    controller->>game: control_action
    Note right of game: game::add_action
    Note right of game: game::process
    game->>user: If no valid control_actions: done!
    game->>chess_piece: piece_action
    Note right of chess_piece: chess_piece::add_action
    Note right of chess_piece: chess_piece::tick
    chess_piece->>chess_piece: process all piece_actions until all are done

The key and mouse talk to user_inputs, or: user_inputs handles all the sf::Events. However, not all events are valid. For example, an LMB can be ignored if all players use the keyboard. user_inputs only keeps the keys that are setup in the 'Key Settings'/'Controls' dialog.

Input	Class	Output
keyboard and mouse input	user_inputs	Store valid input, ignore invalid input

game_controller gets all user_inputs and moves the right cursor (there is one cursor for each player) to the right spots. It can select a piece to do a chess move.

Input	Class	Output
Valid input	game_controller	Moves the cursor, does chess moves

The chess moves that game_controller suggests may not be valid and do not move pieces. game checks if the chess move is valid and if yes, does the move.

Input	Class	Output
Chess moves	game	Performs the valid chess moves, ignores invalid chess moves
